burner plan and elevation with dimensions

Related Questions?

Q1. What are the dimensions of a Free Standing HOB?

The dimensions of a Free Standing HOB are Length: 770 mm (31 inches) and Breadth: 380 mm (15 inches). The height of the HOB is 110 mm (4.5 inches).

Q2. What are the standard sizes of Hobs are available on the market?

There are number of brands who manufacture or design hobs for kitchen uses and it can vary brand to brand and location to location. Some common sizes of Hobs are 600 mm, 700 mm, 750 mm, and 900 mm (24 inches, 28 inches, 30 inches, and 36 inches).

Q3. What is the standard height of a cooktop or worktop in India?

The standard height of a cooktop in India is 850 mm (34 inches). But you can take a height between 750 to 850 mm (30 to 34 inches) as per your comfort zone.

In western countries, the standard height of worktop is between 850 to 950 mm (34 to 38 inches).

To see an image reference of woman working on worktop, click here

Q4. At what height chimney hood should be installed in a kitchen?

A chimney hood should be installed between 600 to 750 mm (24 to 30 inches) from the cooktop in a kitchen.

Q5. Which type of cabinets should be designed below Free Standing Hobs?

Below the hobs or burners, you should design a cutlery drawer {600 to 750 mm (24 to 30 inches)} and a gas storage cabinet {420 to 450 mm (17 to 18 inches)} because it is very comfortable and feasible for the user.

To read the detailed design and interior guide for the Kitchen, click hereā€¦

*Note:- The dimensions written in inches and mm are individual dimensions, not converted.

Highlights

Dimensions:

Length  :- 770 mm

Breadth :- 380 mm

Height :- 110 mm

Materials:

  • Glass Cooktop
  • Brass Burners
  • Aluminum Extruded Black Finish
  • Metallic Knobs

Brand:

Whirlpool

Download:

FREE 2D AutoCAD File
